Refrigerated truck bodies using an IVECO Daily chassis - our CoolerBox2.0 has a lot to offer

Aerodynamic - fuel efficient - outstanding design and payload up to 3954 kg!

  • The ideal solution for fresh or deep-freeze food as well as for delivering meat.
  • Available in various models and sizes, can be modified for fresh food or deep-freeze food service.
  • By using high end materials, our refrigerated body is extremely long-lasting and, should it be damaged, easy to be repaired.
  • Our refrigerated body lasts longer than a car does, meaning it can easily be taken off an old chassis and placed on a new one.
  • Outstanding insulation owing to our DUROLITE® panel technology and DUOFLEX® door sealant system. For this reason, you can expect substantially better refrigeration and lower fuel consumption.
  • Right-angled and smooth-surfaced interior space. This means you can optimize the amount of cases and pallets you load in.
  • Low empty weight owing to constant optimization of its weight and DUROLITE® panel technology.
  • Reliable torsion resistance thanks to KRESS having welded the portal frame fourfold as well as due to two stable stainless steel locks.
  • Outstanding corrosion protection owing to galvanised auxiliary frame.
  • Easy to clean due to standard drains, smooth surface of the interior and precise and careful sealing of all joints.
  • Fulfills all requirements of food hygiene regulation and is HACCP, ATP certified.

An overview of the standard truck body sizes - other dimensions upon request:

Chassis

Wheel base

Size of body [L x W x H]

Loading capacity*

Payload*

Iveco Daily 35

3000 mm

2520 x 1870 x 1350 mm

E2-cases: 99
Euro-pallets: 4

up to 1232 kg

Iveco Daily 35

3000 mm

2520 x 1870 x 1700 mm

E2-cases: 140
Euro pallets: 4

up to 1229 kg

Iveco Daily 35

3450 mm

3320 x 1870 x 1920 mm

E2-cases: 212
Euro-pallets: 5
Rolling container: 8

up to 1078 kg

Iveco Daily 50

3450 mm

3320 x 2050 x 1920 mm

E2-cases: 221
Euro-pallets: 6
Rolling container: 8

up to 2416 kg

Iveco Daily 50

3750 mm

4120 x 2050 x 1920 mm

E2-cases: 266
Euro-pallets: 8
Rolling container: 10

up to 2272 kg

Iveco Daily 65

3750 mm

4120 x 2050 x 1920 mm

E2-cases: 266
Euro-pallets: 8
Rolling container: 10

up to 3284 kg

Iveco Daily 65

4350 mm

4820 x 2220 x 1920 mm

Euro-pallets: 10
Rolling container: 15

up to 3092 kg

Iveco Daily 65

4750 mm

5900 x 2220 x 1920 mm

Euro-pallets: 11
Rolling container: 21

up to 2471 kg

Iveco Daily 70

3750 mm

4120 x 2050 x 1920 mm

E2-cases: 266
Euro-pallets: 8
Rolling container: 10

up to 3954 kg

Iveco Daily 70

4350 mm

4820 x 2470 x 2100 mm

Euro-pallets: 12
Rolling container: 18

up to 3280 kg

Iveco Daily 70

4750 mm

5900 x 2470 x 2100 mm

Euro-pallets: 14
Rolling container: 24

up to 3018 kg

* Dimensions: E2-case = 600x400x200 mm, Euro-pallet = 1200x800 mm, Rolling container = 810x720x1700 mm. Loading capacity and payload depend on chassis, body and specific features.
